Engineered with high-tensile structural steel, compliant with European Standard EN 15512, and rigorously tested for seismic resilience across Israeli industrial corridors.
Heavy-duty 5-layer selective rack system with 500kg+ beam load capacity. Features 50mm pitch adjustability, safety lock pins, and durable powder coating.
View Technical Details
Turnkey prefabricated clear-span steel warehouse structures optimized for seamless integration with high-bay selective pallet racking systems.
View Technical Details
Custom engineered expandable modular steel frames designed to withstand industrial crane loads and heavy automotive spare parts storage racks.
View Technical Details
Ultra-heavy-duty drawer racking designed for injection molds, featuring sliding shelves, top-crane integration, and load ratings up to 2,000kg per level.
View Technical Details
Modular boltless long-span shelving for medium-to-light hand-loaded inventory, retail backrooms, and e-commerce picking channels.
View Technical Details
Foldable zinc-plated wire mesh containers and stacking steel racks engineered for high-density bulk storage and returnable logistics containers.
View Technical Details
Multi-tier structural steel mezzanine platforms and rack-supported floor systems designed to double or triple usable vertical warehouse space.
View Technical Details
Corrosion-resistant electro-galvanized 4-tier wire shelving, fully compliant with cold-chain humidity requirements and cleanroom compliance.
View Technical DetailsModern warehouse logistics in Israel demand uncompromised structural integrity, vertical space optimization, and strict safety compliance. As an established global manufacturer with over 45 years of industrial storage expertise, we supply CE Certified Pallet Rack Beams specifically engineered to meet the demanding requirements of logistics hubs in Haifa, Ashdod, Tel Aviv (Gush Dan), Modi'in, and Emek Hefer.
Pallet rack beams represent the primary horizontal load-bearing members in selective pallet racking, drive-in racking, and high-bay automated warehouse configurations. Deflection parameters, beam-to-column connector rigidity, and material yield strength directly impact operational throughput and warehouse safety. Our structural racking beams are manufactured using high-grade cold-rolled structural steel (Q345B / S355JR grade), complying with European Standard EN 15512 (Steel static storage systems - Adjustable pallet racking systems - Principles for structural design) and FEM 10.2.02 standards.
Rigorously batch-tested for yield strength, weld integrity, and structural deflection compliance (L/200 standard), fully qualified for Israeli import regulations and SII requirements.
Custom engineered beam connectors with multi-claw safety pins, engineered to withstand seismic shear forces along Israel’s Jordan Rift Valley fault line zone.
Available in Box Beam profiles (80mm to 160mm beam height) and Step Beam profiles for seamless wire mesh deck and timber panel integration.
Selecting the correct cross-sectional profile and beam geometry depends on total load per level, clear span width (ranging from 1,800mm to 3,900mm), and pallet footprint (Euro pallets 800x1200mm vs Industrial pallets 1000x1200mm). The table below details standard load capacities for our CE-certified pallet rack beams exported to Israel:
| Beam Section Profile | Material Thickness | Clear Span (mm) | Max Uniformly Distributed Load (UDL / Pair) | Connector Claws | Surface Finish |
|---|---|---|---|---|---|
| Box Beam 80 x 50 mm | 1.5 mm - 1.8 mm | 2,300 mm (2 Euro Pallets) | 1,500 kg / level | 3-Claw Lock Pin | Epoxy Powder Coat (RAL 2004 / 5015) |
| Box Beam 100 x 50 mm | 1.5 mm - 2.0 mm | 2,700 mm (3 Euro Pallets) | 2,200 kg / level | 3 or 4-Claw Lock Pin | Epoxy Powder Coat / Galvanized |
| Box Beam 120 x 50 mm | 1.8 mm - 2.0 mm | 2,700 mm - 3,300 mm | 3,000 kg / level | 4-Claw Heavy Duty | High Durability Epoxy Finish |
| Box Beam 140 x 50 mm | 2.0 mm - 2.5 mm | 3,600 mm (3 Industrial Pallets) | 3,800 kg / level | 4-Claw Heavy Duty | Thermosetting Powder Coat |
| Step Beam 100 x 50 mm | 1.5 mm - 1.8 mm | 2,700 mm | 2,000 kg / level | Integrated Drop-in | Anti-Corrosive Epoxy Finish |
Israel's rapid economic growth and dense urban centers require tailored logistics architecture. Our export division customizes racking beams and upright systems for specific micro-climates and industry requirements across the region:
Warehouses situated within proximity to the Port of Haifa and Port of Ashdod face severe coastal salt-fog atmospheric corrosion. We supply double-sided hot-dip galvanized or C4/C5 marine-grade powder-coated pallet rack beams. These beams resist oxidation, ensuring long-term structural integrity in high-humidity bonded storage facilities.
With industrial land premiums in Tel Aviv, Herzliya, and Petah Tikva driving vertical expansion, warehouses utilize Very Narrow Aisle (VNA) and Automated Storage and Retrieval Systems (AS/RS). Our high-precision cold-rolled box beams feature ultra-tight manufacturing tolerances (±0.5mm) required for robotic shuttle navigation and turret truck access.
Cold storage complexes operating down to -30°C in agricultural hubs require specialized steel ductility. Ordinary structural steel can suffer brittle fractures in deep-freeze environments. Our pallet rack beams use specialized low-temperature carbon structural steel, tested for impact resistance in frozen food and dairy distribution hubs.
Pharmaceutical supply chains servicing major health networks mandate dust-free, hygienic warehouse racking. Our seamless box beams eliminate open top lips where dust accumulates, finished with non-toxic, anti-microbial epoxy powder coatings compliant with cleanroom storage environments.
The Israeli logistics sector is undergoing a profound structural evolution driven by three major market forces:
Since our establishment in 1977, our manufacturing plant has expanded to encompass state-of-the-art continuous roll-forming lines, automated robotic welding stations, and an environmentally compliant powder coating line. When importing pallet racking components into Israel, working directly with an established manufacturer offers crucial operational advantages:
Common inquiries from Israeli procurement managers, warehouse operators, and structural engineering contractors.
Planning a new warehouse installation, mezzanine platform, or high-bay racking extension in Israel? Contact our senior engineering team for layout CAD design, beam load analysis, and factory-direct export pricing.
