Storing liquids in drums presents distinct workplace safety, environmental, and spatial challenges. Divakaran Storage and Handling Systems Pvt. Ltd. manufactures specialised drum racking systems designed specifically to handle standard 200-litre (55 US gal) cylindrical steel and high-density polyethylene barrels.
Fabricated at our Umbergaon (Gujarat) production facility from structural-grade steel profiles, our barrel racks accommodate multi-tier configurations with curved saddle cradles, roll-off stops, and optional drip catchment containment. Designed to integrate smoothly with standard counterbalance forklifts, hydraulic drum stackers, or overhead hoists, each bay provides 100% direct access and safe fluid decanting.
Select from our field-tested drum storage frameworks engineered for manufacturing tool rooms, chemical warehouses, paint blending plants, and bulk petroleum stores.
Our standard heavy-duty horizontal rack designed for chemical plants and manufacturing storehouses. Equipped with high-tensile steel crossbeams and precision-formed cradle saddles that prevent drum rolling.
| Material | High-Strength Structural Steel |
| Clear Height | Up to 18 Feet (Adjustable Levels) |
| Application | 200L / 55-Gallon Barrels |
| Finish | Powder Coated / Anti-Corrosive Primer |
| Supply Ability | 500 Units / Month |
Engineered with forward drum tilt and dedicated dispensing heights to facilitate fluid extraction via taps and rotary pumps. Built with enhanced clearance for oil drip collection trays.
| Material | Reinforced Heavy-Gauge Steel |
| Clear Height | Customised Up to 18 Feet |
| Function | Storage & Active Fluid Dispensing |
| Handling | Drum Stacker / Forklift Compatible |
| Lead Time | 7 - 10 Days Dispatch |
High-density multi-tier storage configuration engineered for bulk liquid logistics warehouses. Maximises vertical air-rights while ensuring individual barrel accessibility without unstacking.
| Material | Certified Heavy Steel Profiles |
| Capacity | Up to 1,500 kg per Bay Tier |
| Security | Integrated End-Stops & Side Retainers |
| Customisation | Stainless Steel / Hot-Dip Galvanised |
| Export Pack | CKD Knock-Down Palletised Bundle |
Why plant managers and safety officers choose purpose-engineered horizontal drum racks over hazardous floor palletising.
Retrieve or dispense from any individual drum without disturbing adjacent barrels, preventing costly double-handling and load shifting risks.
Curved drum cradles with heavy-duty end retainers lock cylindrical profiles firmly in place against forklift accidental knocks or seismic vibrations.
Modular layouts facilitate beneath-beam sump trays, preventing chemical, lubricant, or solvent leaks from spreading across workshop floors.
Supplied in complete knock-down (CKD) format, our racks load compactly into standard 20ft/40ft shipping containers for global delivery.
Standard engineering baselines. All systems can be custom fabricated to specific drum diameters, liquid specific gravities, and warehouse heights.
| Parameter | Standard Specification | Heavy-Duty Industrial Option | Custom / Harsh Environment |
|---|---|---|---|
| Drum Compatibility | Standard 200 Litre / 55 Gallon | Steel & Plastic Poly Barrels | Custom Carboys & Cylinders |
| Structural Frame Height | Up to 12 Feet (3.6 Metres) | Up to 18 Feet (5.5 Metres) | Bespoke Ceiling-Matched Pitch |
| Load Capacity Per Level | 800 kg per beam level | 1,200 kg – 1,500 kg per level | Engineered per fluid density |
| Surface Finish | Anti-Rust Epoxy Primer + Enamel | Electrostatic Powder Coated | Hot-Dip Galvanised / 304 SS |
| Drum Orientation | Horizontal cradle rest | Tilt cradle for dispensing | Vertical palletised conversion |
| Handling Equipment | Forklift with drum grab / prongs | Counterbalance forklift / Reach truck | Manual drum tipper / overhead hoist |
Divakaran provides complete warehouse layout planning, structural engineering certifications, and containerised export dispatch for industrial clients worldwide.
